Marathon 1/2 HP Carbonator Motor – OEM Replacement Part 200809

Description

Marathon 1/2 HP Carbonator Motor – 200809

Marathon carbonator ODP motors feature a reversible rotation and are a direct replacement for most carbonator pump motors.

• Specially designed end shield has extended hub and short, slotted shaft for close-coupling the carbonator pump to the motor.
• These motors are used for liquid transfer pumps, vending machine pumps, and other close-coupling pump applications.

Specifications

• Type: Split-Phase
• Enclosure: Open Drip proof
• Mounting: Extended Hub and Cradle or Rigid Base
• Ambient: 40 °C
• Thermal Protection: Auto
• Bearings: Sleeve
• Rotation: CW/CCW
• Shaft: 5/8” Slotted 1144 Steel
• Voltage: 110/220 Volt 50/60 Hz
• Part Number: Description:
• 200809 Marathon Carbonator, 1/2 HP ODP Motor, 1725/1425 RPM 48Y Frame, 110/220 Volt 50/60 Hz
• Axeon, Flexeon, Titan, & RO Ultra Tec replacement part
